Wireless dual channel detector

The detector is intended for detection of an intrusion into a secure space of an enclosed area, glass break-ing and transmission of alarm signal to the Security Hub via radio.

The detector is intended for detection of an intrusion into a secure space of an enclosed area, glass break-ing and transmission of alarm signal to the Security Hub via radio.

Features

  • 2 detection channels: volumetric optoelectronic (PIR), acoustic (AC);
  • ceiling mount;
  • max installation height 3.6 m;
  • microprocessor analysis;
  • tampering control;
  • lithium-thionyl-chloride battery, size AA, 3.6 V, included in the delivery set;
  • average battery lifetime - 3 years;
  • 360° volumetric zone;
  • discrete sensitivity adjustment;
  • temperature compensation;
  • resistance to external light not less than 6500 lux;
  • detection of destruction of ordinary glass, protected by a polymer film, reinforced, patterned, multilayer building, tempered flat.
Name Description
Detection zone 360°
Detection zone diameter (2.4 m instalation) 6 m
Detection zone diameter (3.6 m instalation) 9 m
Recommended installation height 2.4 - 3.6 m
AC detection zone range 6 m
Operating radio frequency 433 MHz
Wireless coverage range 100 m
Transmitter power 10 mW
Current consumption (stand-by mode) 0.13 mA
Current consumption (transmission mode) 25 mA
Power supply voltage 2.8 - 3.6 V
Overall dimensions 108х31 mm
Temperature range -20 to +50 °С
Relative humidity up to 98% at +25 °С
IP protection IP30
