Astra-RVC

Receiver (433 MHz)

RVC (receiver) is a stationary device designed for:
 - receiving signals from TRC via a radio channel,
 - generation of notifications by actuating a built-in relay,

The receiver registers up to 99 TRCs and saves this information when powered off.

The receiver is provided with one power relay.

Receiver (433 MHz)

RVC (receiver) is a stationary device designed for:
 - receiving signals from TRC via a radio channel,
 - generation of notifications by actuating a built-in relay,

The receiver registers up to 99 TRCs and saves this information when powered off.

The receiver is provided with one power relay.

Features

  • Memory capacity - 99 of TRCs;
  • Power relay with 3 terminals (COM-NO-NC);
  • 2 modes of the power relay:

    - opening of contacts for a programmed time from 2 sec to 30 min,
    - opening (closing) contacts until the next command (trigger mode);
  • built-in antenna, external antenna connection supported.
Name Description
Wireless coverage range 300 m
Operating frequency  433 MHz
Power voltage 10.5 - 15 V
Current consumption 75 mA
Boot time 10 sec
Overall dimensions 101х63х32 mm
Relay specification:
Max switched voltage at a load current of 1 A 250 V AC
Max DC load at 30 V:
 - NO terminal
 - NC terminal
5 A
3 A
Temperature range 0 to +50 °С
Relative air humidity up to 95% at +35 °С
IP protection IP30

Passport

Astra-RVC-v9_2_en.pdf
