Motion detector
Detection of intrusion into the protected area and triggering an alarm notification by opening the output contacts of the signal relay.
TEKO
Astra-515 ver. A
Motion detector
Detection of intrusion into the protected area and triggering an alarm notification by opening the output contacts of the signal relay.
Features
- volumetric lens;
- no antisabotage zone;
- discrete sensitivity adjustment;
- optoelectronic relay;
- corner bracket included.
| Parameter | Value |
|---|---|
| detection zone range | 10 m |
| horizontal viewing angle | 90° |
| recommended installation height | 2.4 - 2.5 m |
| resistance to external light | 6500 lx |
| supply voltage | 8 to 15 V |
| max current consumption | 15 mА |
| resistance of the circuit included in the alarm loop | 8 Ohm |
| Overall dimensions | 86×54×41 mm |
| Temperature range | 0 to +50 °С |
| Relative humidity | up to 95% at +35 °С |
| IP protection | IP41 |
