Wireless panic button
Wireless Electro-Contact Panic Button is in-tended for manual activation and transmitting an alarm signal to the Security Hub.
TEKO
Astra-3221
Wireless Electro-Contact Panic Button is in-tended for manual activation and transmitting an alarm signal to the Security Hub.
Features
- stationary or mobile device;
- powering from CR2430 batteries (2 pcs.) included in the delivery set;
- supply voltage control;
- clamp included in the delivery set.
| Name | Description |
|---|---|
| Operating frequency | 433 MHz |
| Current consumption (stand-by mode) | 0.008 mA |
| Current consumption (transmission mode) | 20 mA |
| Wireless coverage range | 1000 m |
| Transmitter power | 10 mW |
| Supply voltage | 2.3 to 3.0 V |
| Overall dimensions | 86х40х20 mm |
| Weight | 0.06 kg |
| Temperature range | -10 to +50 °С |
| Relative humidity | up to 98% at +40 °С |
| IP protection | IP41 |
